EKL1-63B 10kA Type B Residual Current Device (RCD)
Inquire
| Standard | IEC60947-2 |
| Protection | Overcurrent, short circuit, leakage protection, isolation |
| Type of protection | A, AC |
| No.of poles | 1P+N, 2P, 3P, 3P+N, 4P |
| Rated voltage (Ue) | 230V~(1P+N, 2P), 400V~(3P, 3P+N, 4P) |
| Rated currents (In) | 63,80,100,125A |
| Rated sensitivity currents (I△n) | 30,100,300mA |
| Residual current off-time under (I△n) | ≤0.1s |
| Rated insulation voltage (Ui) | 500V |
| Rated frequency | 50/60Hz |
| Rated short-circuit breaking capacity (Icn) | 6,000A, 10,000A |
| Running short-circuit breaking capability (Ics) | 7,500A |
| Rated impulse withstand voltage(1.2/50) (Uimp) | 4,000V |
| Instantaneous trip characteristic | C, D |
| Electrical life | 6,000 Cycles |
| Mechanical life | 20,000 Cycles |
