EKD6-PM32R DC Isolator suitable for panel mounting
Inquire
The EKDBT series PV combiner box is specifically designed for large-scale ground-mounted PV power plants, commercial and industrial rooftops PV power plants, as well as PV systems in complex terrains. It integrates photovoltaic anti-reverse diodes, DC circuit breakers, DC fuses, DC surge protectors, and monitoring devices and using metal box as the enckosure. Suitable for 1000V and 1500V DC photovoltaic systems, the product supports multi-way string in and a maximum output current of 1600A, providing comprehensive protection against short circuits, overloads, surges, reverse currents, and islanding effects.
WUHU ETEK Electric Co., Ltd. specializes in the production of photovoltaic combiner boxes for the international market, can provide product technical design, product brand customization, the company's photovoltaic string box has successfully served many international photovoltaic projects around the world
| Model | EKDBT-PV2/2-FBSD | EKDBT-PV3/1-FBSD | EKDBT-PV4/4-FBSD | EKDBT-PV6/6-FBSD | EKDBT-PV12/1-FBSD | EKDBT-PV16/1-FBSD | ||
| DC input strings | 2 | 3 | 4 | 6 | 12 | 16 | ||
| Output strings (equal to No. of MTTP) |
2 | 1 | 4 | 6 | 1 | 1 | ||
| Max. DC voltage | 600V/1000V | 600V/1000V | 600V/1000V | 600V/1000V | 1000V | 1500V | 1000V | 1500V |
| Max. per string input current | 32A | 32A | 32A | 32A | 32A | 45A | 32A | 45A |
| Max. per string output current | 32A | 100A | 32A | 32A | 385A | 540A | 512A | 720A |
Please download the datasheet : Compnent Parameters
